-Bottle filling solutions for different viscosity of water liquid, semi-fluid and paste.
-Application for 25-5000ml filling in foodstuff/ cosmetics/ medicine, daily chemical, detergent industry.
-Compact machine consctructions, adopt pump filling(cylinder driven or servo motor) or gravity filling.
-S.S316L or plastic contact parts, Anti-drop filling nozzles, option of diving filling process.
-PLC controlled, & trouch screen operation; Easy to clean & maintain.
Model |
APF-6/8/10 |
AGF-6/8/10/12(P) |
Principle |
Piston Pump Filling |
Gravity Filling |
Filling volume |
25-250; 50-500;100-1000;250-2500ml |
25-5000ml |
Speed |
80-100PPM@250ml(10 nozzles) |
60-80PPM@500ml(10 nozzles) |
Nozzles |
Anti-drop/ Diving filling |
Anti-drop/ Diving filling(plastic nozzle) |
Filling Accuracy |
1% |
1% |
Powder supply |
220V/380V; 50Hz, 0.2-0.8kw |
Air Supply |
0.6-0.8Mpa |
Machine weight |
900kg |
600kg |
Machine Size |
W1000-L2000-H2200mm |
W900-L20000-H2300mm |
